Hitachi P 20SF User Manual

English
14
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fi re and/or serious
injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence
of fl ammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
CONTENTS
GENERAL POWER TOOL SAFETY WARNINGS ........................................14
PLANER SAFETY WARNINGS ....................................................................17
SYMBOL .......................................................................................................17
SPECIFICATIONS ........................................................................................ 17
STANDARD ACCESSORIES .......................................................................17
OPTIONAL ACCESSORIES (sold separately)..............................................18
APPLICATIONS ............................................................................................18
PRIOR TO OPERATION ...............................................................................18
PLANING PROCEDURES ............................................................................18
CARBIDE BLADE ASSEMBLY AND DISASSEMBLY AND ADJUSTMENT
OF CUTTER BLADE HEIGHT (FOR DOUBLE EDGED BLADE TYPE) ........20
BLADE ASSEMBLY AND DISASSEMBLY AND ADJUSTMENT OF
BLADE HEIGHT (FOR RESHARPENABLE BLADE TYPE) ..........................22
SHARPENING THE RESHARPENABLE BLADES .......................................23
ATTACHING AND DETACHING THE DUST ADAPTER
(OPTIONAL ACCESSORY) ..........................................................................23
MAINTENANCE AND INSPECTION ............................................................24
SERVICE PARTS LIST .................................................................................25
000BookP20SFChS.indb14000BookP20SFChS.indb14 2016/07/1913:40:442016/07/1913:40:44

Hitachi P 20SF Specifications

General

Input power	620 W
Power source	AC
Idle speed	17000 RPM
Planning width (max)	82 mm
Chip thickness (max)	2.6 mm
Soft grip	Yes
Product color	Green

Weight and Dimensions

Width	296 mm
Weight	2500 g
