Hitachi P 20SF User Manual

English
26
ITEM
NO.
PART NAME Q’TY
1
CUTTER BLOCK ASS’Y
(
W/B.B
)
1
2
PLANER BLADES
(
DOUBLE
EDGE BLADE TYPE
)
2
3 SET PLATE
(
B
)
2
4 SET PLATE
(
A
)
2
5 WASHER M4 4
6 MACHINE SCREW M4 × 5 4
7 BLADE HOLDER 2
9A BOLT M6 6
10
PLANER BLADES 82MM
(
RESHARPENABLE BLADE
TYPE
)
2
17 BALL BEARING 608VVC2PS2L 1
19
BALL BEARING
6200VVCMPS2L
1
20 SCREW PLATE 1
21 TAPPING SCREW D4 × 16 1
22 SPRING 1
23 RUBBER PACKING 1
24 FRONT BASE 1
25 KNOB
(
A
)
1
26 LOCK NUT M10 1
27 KNOB
(
B
)
1
28 WASHER
(
B
)
1
29 BEARING COVER 1
30
TAPPING SCREW
(
W/FLANGE
)
D4 × 12
2
31 TIP COVER 1
32
TAPPING SCREW
(
W/FLANGE
)
D4 × 20
8
33
HEX. SOCKET SET SCREW
M5 × 8
2
34 NAME PLATE 1
35 BRUSH HOLDER 2
36 CARBON BRUSH 2
37 BRUSH CAP 2
38 CORD HOLDER 1
39 BELT COVER 1
40 BELT 1
ITEM
NO.
PART NAME Q’TY
41 PULLY
(
B
)
1
42 END BRACKET 1
43
BALL BEARING
6200VVCMPS2L
1
44 WASHER
(
A
)
1
45 ARMATURE 1
46 FAN GUIDE 1
47 STATOR ASS’Y 1
48 BRUSH TERMINAL 2
49
MACHINE SCREW
(
BLACK
)
M4 × 16
3
50 PULLY
(
A
)
1
51 GRIP COVER 1
52 HANDLE COVER 1
53
HEX. HD. TAPPING SCREW
D4 × 60
2
54 SWITCH 1
55
TAPPING SCREW
(
W/FLANGE
)
D4 × 16
2
56 CORD CLIP 1
57
BALL BEARING
608VVC2PS2L
1
58 FASTON 1
59 HOUSING ASS’Y 1
60 CORD ARMOR D8.8 1
61 CORD 1
62 SPRING 1
63 STAND 1
64 TERMINAL 1
65 NOISE SUPPRESSOR 1
66 CONNECTOR 2
67 INTERNAL WIRE 1
68 REAR BASE 1
69
TAPPING SCREW
(
W/FLANGE
)
D4 × 16
4
502 BOX WRENCH 10MM 1
503 GUIDE 1
504 STOPPER SCREW M5 × 14 1
505 BLADE SHARPENING ASS’Y 1
507 SET GAUGE 1
000BookP20SFChS.indb26000BookP20SFChS.indb26 2016/07/1913:40:452016/07/1913:40:45

Hitachi P 20SF Specifications

General

Input power	620 W
Power source	AC
Idle speed	17000 RPM
Planning width (max)	82 mm
Chip thickness (max)	2.6 mm
Soft grip	Yes
Product color	Green

Weight and Dimensions

Width	296 mm
Weight	2500 g
