Hitachi PLC User Manual

20
R5
Inline box
WR0 = WR1 OR H00FF
WR2 = WR2 + 10
SHL (WM100,1)
TRNS 0 (WX0, WR0, R0)
FUN 80 (WR3)
DIF2
Up to 19 lines
Many commands are available
Basic commands : 35 ∼
Arithmetical commands : 22 ∼
Application commands : 25 ∼
Control commands : 12 ∼
Special function commands : 16 ∼
Comparison box
H3000
<
WX 3
Y100
n
LADDER EDITOR
WX 3
16#3000
GT 0
0.1s
Y100
n
Pro-H (LD)
GT 0
0.1s
Y100
16#3000
WX 3
n
Pro-H (FBD)
WX 3
Y100
While WX 3 exceeds H3000, Y100 is ON.
H3000
* GT : Greater Than
