9 Electrical and control settings
Electrical connection
TCGB0123 rev.2 - 10/2019
112
9.3.2 Minimum requirements of the protection devices
! CAUTION
• Ensure specically that there is an Earth Leakage Breaker (ELB) installed for the units (outdoor and indoor unit).
• If the installation is already equipped with an Earth Leakage Breaker (ELB), ensure that its rated current is large enough to hold the
current of the units (outdoor and indoor unit).
? NOTE
• Electric fuses can be used instead of magnetic Circuit Breakers (CB). In that case, select fuses with similar rated values as the CB.
• The Earth Leakage Breaker (ELB) mentioned on this manual is also commonly known as Residual Current Device (RCD) or Residual
Current Circuit Breaker (RCCB).
• The Circuit Breakers (CB) are also known as Thermal-Magnetic Circuit Breakers or just Magnetic Circuit Breakers (MCB).

Split system - Outdoor unit
Model Power supply
Applicable voltage
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max. (V) U min. (V)
RAS-2WHVRP
1~ 230V 50Hz 253 207
10.4
16
2/40/30RAS-2.5WHVRP 12.9 16
RAS-3WHVRP 15.8 20
MC: Maximum current; CB: Circuit breaker; ELB: Earth leakage breaker

Split system - Indoor unit
YUTAKI S
Model
Power
supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of
poles/A/mA)
U max.
(V)
U min.
(V)
RWM-(2.0-3.0)
NRE(-W)
1~ 230V
50Hz
253 207
Without electric heaters 0.2 5
2/40/30
With electric heater 14.6 16
With DHW tank heater 14.6 16
With electric and DHW tank heaters 28.9 32
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory
“DHWT-(200/300)S-3.0H2E”.
YUTAKI S COMBI
Model
Power
supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of
poles/A/mA)
U max.
(V)
U min.
(V)
RWD-(2.0-3.0)
NRW(S)E-(200/260)
S(-K)(-W)
1~ 230V
50Hz
253 207
Without electric heaters
0.2
5
2/40/30
With electric heater
14.6
16
With DHW tank heater
12.7
16
With electric and DHW tank heaters
27.1
32

Monobloc system - YUTAKI M
Model
Power
supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of
poles/A/mA)
U max.
(V)
U min.
(V)
RASM-2VRE
1~ 230V
50Hz
253 207
Without DHW tank heater 10.6 16
2/40/30With DHW tank heater 23.1 32
RASM-3VRE
Without DHW tank heater 16.0 20
With DHW tank heater 28.5 32 2/40/30
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory “DHWT-(200/300)S-3.0H2E”.
