3.2 TransportationandHandling
Do not put any material on the product. Do not
step on the product.
Do not put any foreign material into the indoor
unit and check to ensure that no foreign
material exists in the indoor unit before the
installation and the test run. Otherwise, a re
or failure, etc. may occur.
•
 Transporttheproductasclosetotheinstallation
locationaspracticalbeforeunpacking.
(3) Pushthesidecoverforwardtoremovethe
 hooksandthehookingplate.
(4) Removethesidecovertoliftupward.
•
 Whentheindoorunitisunpacked,moved
andinstalled,donottaketheairinletgrille,
louverandlowercover.Additionally,donot
applyanexcessiveforcetothem.Theairinlet
grille,louverandlowercoveraredeformedor
damaged.
•
 Donotputanymaterialontheindoorunit.
•
 Removethesidecoverwhentheindoorunitis
movedafterunpacking.Ifnot,thesidecover
maybedamagedsothatmaycauseinjury.
 <RemovingSideCover>
(1) Opentheairinletgrille.
(2) Removethexingscrew(M4).
3. Before Installation
3.1 CombinationofOutdoorUnitandIndoor
Unit
Thecombinationcapacityofindoorunitagainst
theoutdoorunitisselectedbytheoutdoorunit
capacity.Refertotheinstallationmanualof
outdoorunitandselecttheindoorunitandthe
outdoorunittobesatisedthecombinationunit
numberandthecombinationunitcapacity.
● The indoor unit covers are resin made.
Do not apply an excessive force to the resin
covers or make it fall.
● Do not move the louver by hand. If moved,
the louver mechanism will be damaged.
Toavoiddamagetotheresincovers,beforelifting
ormovingtheindoorunit,putaclothontheresin
covers.
Fixing Screw
(M4)
Position for Fixing Screw
Hooking Plate
Hooks
(3 Portions)
Air Inlet Grille
Side Cove
r
Louver
Lower Cover
Side Cover
Side Cover
Do not handle the side cover.
