PMPT0126A rev.2 - 11/2006

Português

NOME DAS PEÇAS &

DADOS DIMENSIONAIS

PARTE II INSTALAÇÃO

8. NOME DAS PEÇAS

8.1. RASC-5HNE

N.º Nome de peça

1 Painel da saída de ar

2 Painel da entrada de ar

3 Válvula de retenção para linha de gás

4 Válvula de retenção para linha de líquido

5 Protector da válvula de retenção (*)

6 Protector da tubagem de esgoto (*)

7 Tubagem de esgoto

8 Tabuleiro de esgoto

(*) Protecção de transporte: Deve ser removida

durante a instalação
