MAINTENANCE
1.4 Removing Lower Service Cover and Rear Cover
(1) Remove the service cover.
(2) Remove the securing screws for the side cover and remove the side cover pulling it downward.
(3) Remove the securing screws for rear cover and remove the rear cover by pulling it downward.
Tool Gloves, Phillips Screwdriver
Model: 3~3.5HP
Model: 4~6.5HP
Model: 7~12HP
