Hitachi UHD8610PC User Manual

English - 33 -
Command received by display
Reply sent
by display for
successful
operation
Byte Number 0 1 2 3 4 5 6 7 8 9 10 11 12
0 1 2 Notes
Header Data
Header
code
Packet
Data
Size
CRC

Action Type
Setting
code
Name Operation L H L H L H L H L H L H
Monitor
ON BE EF 03 06 00 19 D3 02 00 00 60 02 00 06
OFF BE EF 03 06 00 19 D3 02 00 00 60 01 00 06
GET BE EF 03 06 00 19 D8 03 00 00 60 07 00 1D 00 XY
XY can be either 00 or 01. 00

Mute
ON BE EF 03 06 00 D6 D2 01 00 02 20 01 00 06
OFF BE EF 03 06 00 46 D3 01 00 02 20 00 00 06
GET BE EF 03 06 00 75 D3 02 00 02 20 00 00 1D 00 XY
XY can be either 00 or 01. 00

Screen
ON BE EF 03 06 00 6B D9 01 00 20 30 01 00 06
OFF BE EF 03 06 00 FB D8 01 00 20 30 00 00 06
GET BE EF 03 06 00 C8 D8 02 00 20 30 00 00 1D 00 XY
XY can be either 00 or 01. 00

Source
OPS BE EF 03 06 00 FE D2 01 00 00 20 00 00 06
HDMI BE EF 03 06 00 0E D2 01 00 00 20 03 00 06
VGA BE EF 03 06 00 6E D2 01 00 00 20 01 00 06
FAV BE EF 03 06 00 00 00 01 00 00 20 05 00 06
Source
HDMI2 BE EF 03 06 00 00 00 01 00 00 20 08 00 06
YPbPr BE EF 03 06 00 00 00 01 00 00 20 0B 00 06
DP BE EF 03 06 00 00 00 01 00 00 20 13 00 06
WIDI BE EF 03 06 00 00 00 01 00 00 20 15 00 06
GET BE EF 03 06 00 CD D2 02 00 00 20 00 00 1D 00 XY
XY can be one of the following:
   
    

Note that all of the sources are
not enabled.
Volume
GET BE EF 03 06 00 31 D3 02 00 01 20 00 00 1D 00 XY
INCREMENT BE EF 03 06 00 57 D3 04 00 01 20 00 00 06
DECREMENT BE EF 03 06 00 86 D2 05 00 01 20 00 00 06
SET BE EF 03 06 00 31
D3 03 00 01 20 01 XY 06
XY can take 00 as a minimum
and 1D as a maximum.
