English - 38 -
Audio
2 x 12 W Audio Output Power
Network Connection
Ethernet (LAN) for Internet connectivity
802.11 a/b/g/n built in WIFI Support (optional)
Input/Output Ports
1 x USB 2.0 port (500mA)
1 x USB 3.0 port (1A)
1 x Internal USB 2.0 port (500mA)
1 x HDMI 2.0 In port
1 x HDMI 1.4 or 2.0
1 x Micro USB
1 x VGA port
1 x Audio input port
1 x Audio output port
1 x RS232 port
1 x RJ12 port service use only
1 x Video In port
1 x YPbPr port
1 x SPDIF Coaxial Out port
1 x Diplay Port v1.2 In
1 x Diplay Port v1.2 Out
1 x Headphone port
1 x IR port
OPS
Up to 40w
Power
With OPS : 110-240V AC 50-60Hz 3600mA
W/O OPS : 110-240V AC 50-60Hz 3200mA
Weight (kg)
36
Display Dimensions DxLxH (mm)
1975mm x 1146mm x 103mm
OPS MODULE - SKYLAKE
CPU:
Intel
®
Core
TM
i5-6200U Processor
3MB L3 smart cache
15W TDP
System Memory:
2 x SO-DIMM DDR3L
Up to 16GB
Network:
LAN: 10/100/1000 Mbps LAN support
WLAN: 802.11 a/g/n wireless support
Bluetooth 4.0
Storage:
256GB SSD
Input/Output Ports:
1 x RS232
1 x RJ45
1 x VGA
1 x Mic-In / Line-Out
2 x WiFi antenna
Frequency Ranges
Max Output
Power
< 100 mW
5150 - 5250 MHz (CH36 - CH48) < 200 mW
5250 - 5350 MHz (CH52 - CH64) < 200 mW
5470 - 5725 MHz (CH100 - CH140) < 200 mW
Country Restrictions
all EU countries (and other countries following the
relevant EU directive) without any limitation except
for the countries mentioned below.
Country Restriction
Bulgaria
General authorization required for outdoor
use and public service
France In-door use only for 2454-2483.5 MHz
Italy
authorization is required
Greece
In-door use only for 5470 MHz to 5725
MHz band
Luxembourg
General authorization required for network
and service supply(not for spectrum)
Norway
Radio transmission is prohibited for the
geographical area within a radius of 20 km
from the centre of Ny-Ålesund
Russian Fed-
eration
In-door use only
The requirements for any country may change at any
authorities for the current status of their national reg-
