-12-
MN1-5531 Rev. 10
2-2. Specications
2-2-1. Specications of the probe
Application regions: Intraoperative diagnosis
With the exception of Japan neurosurgery applications are possible if
our recommended transducer cover is attached to our probe.
Form of application to patient: Intraoperative
With the exception of Japan neurosurgery applications are possible if
our recommended transducer cover is attached to our probe.
Connectable instruments: SSD-α5,SSD-α10,Prosound α7,Prosound F75
Field of view: 65°
Frequency: 4～10MHz
Cable length: 3.0 m
Weight: 800 g
Service life: Three years
Range of applied part As shown in the gure below.
Parts treated as applied parts Probe tip itself and 20 cm of the cable near the probe tip.
IPX7 range As shown in the gure below.(waterproof cover MP-2790 unattached)
Whole parts of the probe. (waterproof cover attached)
External dimensions: As shown in the gure below.
Remarks
The dimensions and weight are within ±10% of the indicated values.
Unit: mm
Cable length
Range of applied part
IPX7 range
1000
