English
11
SPECIFICATIONS
Motor Single-Phase, Series Commutator Motor
Power Source Single-Phase, 120 V AC 60 Hz
Current 8 A
Capacities (1) Material: Concrete reinforcing bars only
(for ASTM)
GRADE 40, GRADE 60
(2) Bar Designation Size
#3, #4, #5 (3/8", 1/2", 5/8")
Cutting Bending
#3 (3/8")..... 2 pieces #3 (3/8") .... 3 pieces
Number of piece(s) that
#4 (1/2")..... 1 piece #4 (1/2") .... 2 pieces
can be processed at one time
#5 (5/8")..... 1 piece #5 (5/8") .... 1 piece
No-Load Speed 0 – 16/min.
Weight (without cord) 39.7 lbs (18.0 kg)
Fig. 3 Fig. 4
When installing the deflection When folding the deflection
guard guard
Arm
Guard
Base
Guard
Arm
