Fig. 22
Boulon
Ecrou
Orifice de
fixation de
l’outil
Couvercle arrière
Vis de
fixation
8. Utilisation de l’orifice pour fixer l’outil
Un orifice est prévu au centre de l’outil pour le fixer
et le stabiliser. Cet orifice est très pratique lorsqu’on
l’utilise de la manière suivante. (Fig. 22)
Pour fixer l’outil sur un établi lors d’une opération
de cintrage
Cet orifice est très pratique pour boulonner
l’outil sur un établi. (Dimension du boulon M10,
moins de W3/8)
