2. Facing the front of the rack, nd an empty 2U location where you will install the
controller.
3. Place the left mounting rail as shown in the following gure, and then use two
athead screws to secure the rails to the front vertical post on the rack.
Note: The athead screws are M5x10 (PZ-2), where PZ-2 refers to the
size and type of the Philips head).
Step 2: Install the storage system into a rack
Installing your storage system
Storage system installation (without SVP) 5
