Item Description
1 POWER LED on the front of the controller
3. If the front bezels are not attached to the front of the controller and drive tray,
attach them as follows:
a. Line up the two tabs on the left side of the controller or drive tray with the two
slots on the left side of the bezel.
b. Connect the bezel by sliding it on and swinging the bezel closed.
c. Use the key to secure the bezel to the front of the unit.
Step 5: Power on the storage system
Installing your storage system
Storage system installation (without SVP) 14
