Item Description
Storage System Type Type of the storage system
Serial Number Serial number of the storage system
IP Address IP address of the SVP
Software Versions Version of the following programs.
• Main
• DKB
• ROM BOOT
• RAM BOOT
• Expander
• Config
• CFM
• HDD
• Printout Tool
• CHB (iSCSI)
• CHB (FC16G)
• CHB (FC32G)
• GUM
• Unified Hypervisor
• NASFWINST
• NASFW
Number of CUs The number of control units in the storage system
Shared Memory Size (GB) Capacity of shared memory
Includes the cache management information (directory)
Cache Size (GB) Capacity of the cache
Number of DKBs The number of disk boards on the module
System Options List of the system options specified for the storage system
Drive Capacity (TB) Total capacity of drives in the storage system except for external volumes
Spare Drive Capacity (TB) Total capacity of the spare drives in the storage system
Free Drive Capacity (GB) Total capacity of the free drives in the storage system
Volume Capacity (GB)
1
List of the capacity of the open volumes
Number of LDEVs
1
List of the numbers of the volumes in the following status.
• Allocated
• Unallocated
• Reserved
• V-VOL
Notes:
1. You cannot sort the list.
Reports in graphical view
The reports described in this topic display as graphics.
icons are displayed
before the names of reports in graphical view. If the icons or graphics are not
displayed properly, update the window.
302 Examples of storage configuration reports
