16
Code Function Name Setting Range
Setting During
Operation
(allowed or not)
Change During
Operation
(allowed or not)
Default
Setting
Others
b088 Restart mode after FRS
00 (starting with 0 Hz) /
01 (starting with matching frequency) /
02 (starting with active matching frequency)
× ○ 00
b089 Automatic carrier frequency reduction
00 (disabled) /
01 (enabled [output current controlled]) /
02 (enabled [n temperature controlled])
× × 01
b090 Dynamic braking usage ratio 0.0 to 100.0 [%] × ○ 0.0
b091 Stop mode selection
00 (deceleration until stop) /
01 (free-run stop)
× ○ 00
b092 Cooling fan control
00 (fan always ON) /
01 (ON fan only during inverter operation
[including 5 minutes after power-on and power-off])/
02 (n temperature controlled)
× ○ 01
b093 Accumulated time clear of the cooling fan 00 (count) / 01 (clear) × × 00
b094 Initialization target data setting
00 (All parameters) /
01 (All parameters except in/output terminals and communication) /
02 (Uxxx) /
03 (expect Uxxx)
× × 00
b095 Dynamic braking control (BRD) selection
00 (disabled) /
01 (enabled [disabled while the inverter is stopped]) /
02 (enabled [enabled also while the inverter is stopped])
× ○ 01
b096 BRD activation level 330 to 380 / 660 to 760 [V] × ○ 360 / 720
Free-setting V/ f pattern
b100 Free-setting V/ F freq. (1) 0. to b102 [Hz] × × 0.
b101 Free-setting V/ F volt. (1) 0.0 to 800.0 [V] × × 0.0
b102 Free-setting V/ F freq. (2) 0. to b104 [Hz] × × 0.
b103 Free-setting V/ F volt. (2) 0.0 to 800.0 [V] × × 0.0
b104 Free-setting V/ F freq. (3) 0. to b106 [Hz] × × 0.
b105 Free-setting V/ F volt. (3) 0.0 to 800.0 [V] × × 0.0
b106 Free-setting V/ F freq. (4) 0. to b108 [Hz] × × 0.
b107 Free-setting V/ F volt. (4) 0.0 to 800.0 [V] × × 0.0
b108 Free-setting V/ F freq. (5) 0. to b110 [Hz] × × 0.
b109 Free-setting V/ F volt. (5) 0.0 to 800.0 [V] × × 0.0
b110 Free-setting V/ F freq. (6) 0. to b112 [Hz] × × 0.
b111 Free-setting V / F volt. (6) 0.0 to 800.0 [V] × × 0.0
b112 Free-setting V/ F freq. (7) 0. to 400 ( to 1000) [Hz] × × 0.
b113 Free-setting V/ F volt. (7) 0.0 to 800.0 [V] × × 0.0
Others
b120 Brake control enable 00 (disabled) / 01 (enabled) × ○ 00
b121 Brake Wait Time for Release 0.00 to 5.00 [s] × ○ 0.00
b122 Brake Wait Time for Acceleration 0.00 to 5.00 [s] × ○ 0.00
b123 Brake Wait Time for Stopping 0.00 to 5.00 [s] × ○ 0.00
b124 Brake Wait Time for Conrmation 0.00 to 5.00 [s] × ○ 0.00
b125 Brake release freq. setting 0.00 to 99.99 /100.0 to 400.0 [Hz] × ○ 0.00
b126 Brake release current setting Set range: 0 to 200% of inverter rated current [A] × ○
Rated current
of inverter
b127 Braking frequency 0.00 to 99.99 / 100.0 to 400.0 [Hz] × ○ 0.00
b130 Over-voltage LADSTOP enable 00 (disabled) / 01 (enabled) / 02 (enabled with acceleration) × ○ 00
b131 Over-voltage LADSTOP level 330 to 395 / 660 to 790 [V] × ○ 380/ 760
b132 DC bus AVR constant setting 0.10 to 30.00 (s) × ○ 1.00
b133 DC bus AVR for decel. Proportional-gain 0.00 to 5.00 ○ ○ 0.20
b134 DC bus AVR for decel. Integral-time 0.0 to 150.0 [s] ○ ○ 1.0
b145 GS input performance selection 00 (non Trip) / 01 (Trip) × ○ 00
b150 Panel Display selection d001 to d060 ○ ○ 001
b160 1st parameter of Double Monitor d001 to d030 ○ ○ 001
b161 2nd parameter of Double Monitor d001 to d030 ○ ○ 002
b163 Data change mode selection of d001 and d007 00 (disabled) / 01 (enabled) ○ ○ 00
b164 Automatic return to the initial display 00 (disabled) / 01 (enabled) ○ ○ 00
b165 Action selection in case of external operator disconnection
00 (tripping) /
01 (tripping after decelerating and stopping the motor) /
02 (ignoring errors) /
03 (stopping the motor after free-running) /
04 (decelerating and stopping the motor)
○ ○ 02
b171 Inverter mode selection 00 (disabled) / 01 (IM enabled) × × 00
b180 Initialization trigger 00 (disabled) / 01 (enabled) × × 00
Password
b190 Password A setting 0 (disabled) / 0001 to FFFF (enabled) × × 0000
b191 Password A for authentication 0000 to FFFF × × 0000
b192 Password B setting 0 (disabled) / 0001 to FFFF (enabled) × × 0000
b193 Password B for authentication 0000 to FFFF × × 0000
Function List
[ ○ = Allowed × = Not parmitted]
