Hitachi WJ200 Series

Program Flowchart and Index
Page 13 of 15
Functionality Table (based on contact status)
Up (AC1)
Up / Hi Speed
(AC1 &AC3)
Down (AC2)
Down / Hi Speed
(AC2 & AC3)
Side Limit (AC4)
Up Limit (AC5)
Motor Output
Open Open Open Open Closed Closed No motor output
Closed Open Open Open Closed Closed Up at Min. speed or last speed
Closed Closed Open Open Closed Closed Up, accelerates to Max speed
Open Open Closed Open Closed Closed Down at Min. or last speed
Open Open Closed Closed Closed Closed Down, accelerates to Max. speed
Closed Open Open Open Open Closed Up, only at Min. speed
Closed Closed Open Open Open Closed Up, only at Min. speed
Open Open Closed Open Open Closed Down, only at Min. speed
Open Open Closed Closed Open Closed Down, only at Min. speed
Closed Open Open Open Closed Open No motor output
Closed Closed Open Open Closed Open No motor output
Open Open Closed Open Closed Open Down at Min. or last speed
Open Open Closed Closed Closed Open Down, accelerates to Max. speed
Closed Open Closed Open Closed Closed No motor output
Closed Closed Closed Closed Closed Closed No motor output
Closed Closed Closed Open Closed Closed No motor output
Closed Open Closed Closed Closed Closed No motor output
Closed Closed Closed Closed Open Closed No motor output
Closed Closed Closed Open Closed Open No motor output
