TRANSPORTING
6-69
ZX850LC-3 (BACKHOE)
Types of Packings for Transportation
<Type 2>
Base Machine without
Front Attachment
Counterweight
Boom
Arm
Bucket
Two Boom Cylinders
Four Hydraulic Hoses
Three Side Steps
<Type 1>
Base Machine without
Front Attachment and
Side Frames
Two Side Frames
Counterweight
Boom
Arm
Bucket
Two Boom Cylinders
Four Hydraulic Hoses
Three Side Steps
Part Groups Other Than Sub-Unit Assemblies
The following part groups required re-connection or
reinstallation of the sub-unit assemblies to prepare
for shipping.
Part Group
Type 1 Type 2
Weight Weight
kg (lb) kg (lb)
Counterweight Installation Parts 33 (73) 33 (73)
Track Frame Installation Parts 136 (300) 62 (140)
Hand Rails and Related Parts 44 (97) 44 (97)
