DRIVING MACHINE
4-2
Starting to Move
d
WARNING: Start to move the machine only after
checking that no personnel and/or obstacles are
present around the machine.
Never turn ride control switch (3) (optional) to ON
position when traveling the machine or raising the
bucket. Before turning the ride control switch (3) ON,
stop the machine and confirm the safety around the
bucket. Avoid turning ride control switch (3) (optional)
to ON position while traveling the machine. Failure to
do so may automatically move the lift arm up or down.
Refer to page 1-64 for detailed information of ride control
switch (3).
1. Check that none of the warning indicators except
parking brake indicator (1) on the monitor panel is ON.
2. Set the front attachment in the driving position by
operating control lever (2).
MNDB-01-005
3
2
1
MPTC-01-019
A
Driving Position
A: 350 to 400 mm (13.8 to 15.7 in)
MNSC-04-001
To Next Page
