OPERATOR’S STATION
1-6
System Failure Indicator
The system failure indicator comes ON or flashes an
abnormality may be present in the engine control system
(optional: Except ZX27U
-2). If the system failure indicator
comes ON or flashes, immediately contact your author-
ized dealer for repair.
Engine Oil Pressure Indicator
The red indicator will light when the engine oil pressure
is low. If the red indicator comes ON, the engine oil
pressure warning buzzer will sound at the same time.
Immediately stop the engine. Check the engine oil
pressure system and the oil level for any abnormality.
Overheat Indicator
If the coolant temperature rises extremely high, this in-
dicator operates. If the red light comes ON, the buzzer
sounds at the same time.
Immediately stop machine operation and reduce engine
speed to the slow idle speed to lower the coolant tem-
perature.
Fuel Level Indicator
When the fuel level indicator comes ON while the ma-
chine is operating on level ground, the remaining fuel
amount in the fuel tank is as shown in the table below.
Refill the fuel as soon as possible.
Model Remaining Fuel Amount
ZX27U-2, ZX30U-2, ZX35U-2 6.5 litters (1.7 US gal)
ZX40U-2, ZX50U-2 11 litters(2.9 US gal)
M1M7-01-008
M178-01-037
M178-01-036
M178-01-034
To Next Page
