HITROL HT-100RT - 2. Specifications

2. Specifications
Items
Specifications
Model
M-100RD (Compact), M-RIU (Local)
Microprocessor
16Bit Microprocessor
Current Loop Interface
2-Wire Loop Current
Supply Voltage
DC+17V ~ +40V @ Typ.+24V
Output Current Accuracy
4.0mA ~ 20.0mA @ ±0.2% F.S
Resolution
±10mm @ With Sensor
Output Current Range
■ 3.8mA ~ 20.5mA @ Alarm 3.6mA, 21mA [NAMUR NE43]
■ 4.0mA ~ 20.0mA @ NAMUR NE43 Holding
Output Current Offset
■ Zero: 3.9 ~ 4.1mA
±0.1mA @ 0.01mA Step
■ Span: 19.9 ~ 20.1mA
Measurement Sensor Range
■ Min. : 200Ω [100mm]
■ Max. : 12KΩ [6M) @ 20Ω Sensor
Output Current Definite
TP
Damping Time
■ Default 0.5 sec
■ Range: 0 sec ~ 10 sec @ 0.5 sec Step ADJ.
Self-Diagnosis
■ Missing the float from sensor
3.6mA current out
■ Disconnected Sensor Cable
■ Lower than Zero Position
3.6mA current output
[NAMUR NE43]
■ Higher than Span Position
21mA current output
[NAMUR NE43]
Simulation Current Out
■ 4mA @ 5 sec
■ 12mA @ 5 sec
■ 20mA @ 5 sec
Status Indicator
Bi-Color LED [Green / Red / Orange]
Setting Menu
Quick Menu / Set Menu / UART
Display
mA, %, m, ft, Level, Distance
Ambient Temperature
-20℃ ~ +60℃
[Table 1] Specifications
