HITROL HT-100RT - 3. Configuration of Setting Menu

3. Configuration of Setting Menu
No.
Content
Description
Remarks
[00]
Select Unit : mA / %
: mA
: % (※ Unit Setting for [02], [03])
[01]
Select Level / Distance
: Level
: Distance
Quick Menu
[02]
Zero Setting
Setting 0.0% ~ 95.0% or 4.000 mA ~ 19.200 mA (Float :
Zero position)
Quick
Menu
[03]
Span Setting
Setting Span 5.0% ~ 100.0% or 4.800 mA ~ 20.000 mA
(Float : Span position)
Quick
Menu
[04]
Zero Height Setting
Based on the setting of level
※ -9.999 ~ 99.999mm (User Setting)
[05]
Span Height Setting
[06]
Tank Height Setting
[07]
Auto Set
Yes: Execution, No: Non-execution
Quick Menu
[08]
NAMUR NE43 Set
NAMUR NE43 function setting and holding
[10]
Damping Time Setting
0 ~ 10 sec. (Default 0.5 sec. @ 0.5 sec. Step ADJ.)
[11]
Offset : Zero Position
When changing float position virtually
※ -10 ~ +90mm @ 10mm Step (User Setting)
[12]
Offset : Span Position
[20]
Offset : Current of Zero
Adjust offset for current output
※ -0.100 ~ 0.100 mA @ 0.001 mA Step ADJ.
[21]
Offset : Current of Span
[30]
Rotation Interval Setting
0.5 ~ 10 sec. (Default 1 sec @ 0.5 sec Step ADJ.)
[31]
‘mA’ Display On/Off
Display ‘mA’ on/off at rotation mode
[32]
‘%’ Display On/Off
Display ‘%’ on/off at rotation mode
[33]
‘Meter’ Display On/Off
Display ‘M’ on/off at rotation mode
[34]
‘Feet’ Display On/Off
Display ‘ft’ on/off at rotation mode
[40]
Output Current “4mA”
Output “4mA” current for 5 seconds
Quick
Menu
Output Current “12mA”
Output “12mA” current for 5 seconds
Output Current “20mA”
Output “20mA” current for 5 seconds
[90]
Show Error Number
Display configuration number of error
[91]
Show Voltage Value
Display the zero, span, current voltage of sensor
[100]
Factory Reset
Reset the setting value
[Table 2] Setting Menu List
