Folding Operation Diagram:
1: Unscrew the safety buckle on the
vertical tube folding quick
release,and then loosen the quick
release,the vertical tube can be
folded;
2: Loosen the seat tube up and
down t o adjust the quick
release, adjust the seat tube to
the lowest position;
3: Loosen the vertical pipe
upand down to adjust the
quick release;
T
4.Pull outwards quick-release
trigger, then bike frame can be
folded.
5: Press the pedal inward with
your hand, and then flip it up to
fold the pedal;
Install And Remove Battery Diagram:
EN
l.Turn the key left firstly, then hold it
to push inwards and turn left
continuely.
After this, the lock is opened.
2.After unlocking, press and hold
the seat buckle, turn the seat to
the front, pull up the battery
handle to take out the battery.
3.Have the slot on battery pack
aligned with slideway, then put the
battery into frame. It will be locked
after the key being turned right two
times continuously.
Charging Diagram:
l.The charging port is on the right
side ofthe battery. Except for the
charging time, please cover the
charging port with a protective
cover.
2.Remove the protective cover,
connect the charger and start
charging.
3.When charger's indicator turns
from red to green, the battery has
been charged full. Have button
pressed down and hold, the battery
power capacity will be shown on
LCD.
⑶
