HITWAY BK5 - Unfold Bike; Unfolding Procedure

PRODUCT PARAMETER
PARAMETER
STANDARD VERSION
OUTLOOK
&
DIMENSION
BODY MATERIAL
Q195 carbon structural steel
FOLDED SIZE
750*390*690mm
EXPANDED SIZE
1280*530*1000mm
PEDAL DISTANCE FROM THE GROUND
100mm
WHEEL SIZE
16 inches
PACKING SIZE
790*390*630mm
SPECIFICATIONS
BODYWEIGHT
G.W.:26.5kgs N.W.:24kgs
MAXIMUM LOAD
120kg
REAR SHELF LOAD
less than 15kg (can't carry people)
MAX SPEED
25km/h
CRUISING RANGE
40±5km
MAXIMUM CLIMBING ANGLE
25 degrees
POWER CONSUMPTION PER HUNDRED KILOMETERS
OPERATING TEMPERATURE
-10〜45°C
WATERPROOF DEGREE
IP54
ELECTRONIC
PARAMETER
BATTERY TYPE
18650 lithium ion power battery
BATTERY CAPACITY
7.5AH
BATTERY RATE VOLTAGE
36V
MOTOR DRIVE MODE
Manpower Assist
MOTOR RATED SPEED
420±10r7min
MOTOR RATED VOLTAGE
36V
MOTOR RATED POWER
250W
CHARGING VOLTAGE
DC42V
INPUT VOLTAGE
AC220V
UNDERVOLTAGE PROTECTION VALUE
29V
OVERCURRENT PROTECTION VALUE
1.5A
CHARGING TIME
4-5hours
FEATURES
INSTRUMENT DISPLAY
Multi-function LCD screen
FRONT LIGHTING
Applicable
BRAKING METHOD
Front and rear double disc brakes
TIRE STYLE
Pneumatic tire
Remarks: The factors, including Battery power capacity, load, tire pressure, road environment, chain and wheel
axle lubrication, etc., will affect the maximum speed; the cruising distance indicated in this manual file is the test
result from the riding test conducted uninterruptedly with load of 60kg, at the speed of 15-25km/h, and on the flat
and hardened road surface, from full charge to full power consumption.; Driving habits, temperature, load, tire
pressure, road environment and other factors will affect the actual cruising distance.
