Operations Manual
HKS 700E
9
3.6. Information about fuels and lubricants
Fuel: Automobile fuel, unleaded premium
95 Octane (RON) minimums or
aviation gasoline 100LL.
Fuel pressure: 15 - 40 kPa
(0.15 - 0.4
kgf/cm
2
, 2.2 - 5.8 psi)
Oil type: No
aircraft engine oils.
Only
multi-grade brand-name 100% synthetic
oils for AUTOMOBILE engines, according to
API-classification (API min. SJ).
Take the viscosity of the oil as below table.
Oil volume: 4 Liters (4.2 quarts)
This will vary based on the oil line layout and oil cooler size used.
Oil level is between 1/2 and 2/3 of oil tank after 3 minutes idling.
Oil consumption: Max. 0.1 L/h (1/10th quart per hour)
Oil pressure:
Min.490 kPa (5.0
kgf/cm
2
,71psi) @6200 r/min
Min.118 kPa (1.2
kgf/cm
2
,17 psi) @ idle r/min
Oil temperature (readings off of the feed line into engine):
Min. 50 Deg.C (122 Deg. F)
Max.120 Deg.C (248 Deg. F)
Optimum oil temperature range: 80 - 100 Deg.C (170 - 212 Deg.F)
CAUTION!
z Don't use any aircraft engine oils and additives.
z You must install the oil cooler in the return line to the oil tank.
z Fuel with more than 5% alcohol added must not be used.
