Operations Manual
HKS 700E
24
7.8. Resistance of electrical equipment
Check the resistance of the electrical equipment according to TABLE 2.
TABLE 2.
EQUIPMENT LOCATION OF MEASUREMENT RESISTANCE VARIATION
AC Magnetic White - White of 3 phase 0.4ohms + - 20%
stator connector
Pulse detector White - Red 310 ohms
Brown - Green
Ignition coil Orange - center core 0.2 ohms
High tension coil 4.9 K-ohms
