INSTALLATION
(1) Disconnect the negative cable from the battery.
٨This manual shows a typical installation. Actual installation may vary depending on the vehicle
application.
1. Removal of the Battery Cable
2. Hose Connection Layout
˴
٨Do not install this product on a 24V vehicle. It may cause a fire.
WARNING
1. Removal of the Battery Cable
2. Hose Connection Layout
˴
˴
3. Wiring
4. Mounting the Components
5. After Installation
2-1. Connecting the Boost Sensor
2-2. Connecting the Solenoid Valve
2-3. Connection of a Swing Valve Type
2-4. Connection of a Poppet Valve Type
(1) Considering the hose and harness lengths, determine the appropriate mounting layout
of the Display Unit, Control Unit, Boost Sensor, and Solenoid Valve.
ADVICE
Leave some slack for the harnesses and hoses to avoid tension during engine movement.
Do not install any components in high temperature areas.
To Next Page
