OM−221 534 Page 3
SECTION 2 − SPECIFICATIONS
XFS Technical Specifications (Fixed Shade No.10)
Cartridge Dimensions 4.33 x 3.54 x 0.39 in. (110 x 90 x 10 mm)
Viewing Field 3.75 x 1.37 in. (95 x 35 mm)
Reaction Time Light To Dark: 0.00028 second (1/3,600)
Dark To Light: 0.12 Second
Available Shades Darkened State: No. 10 / Light State: No. 3
Sensors Independent (2)
Operating Temperature 23F to 131F (−5C to +55C)
Storage Temperature −4F to 176F (−20C to +80C)
Power Supply Battery-Powered, Solar Rechargeable
(Internal, Non-Replaceable Lithium Battery)
Total Weight 0.9 lb (410g)
Standards ANSI Z87.1-2003/CSA
Warranty 2 Years From Date Of Purchase (See Section 9)
XVS Technical Specifications (No. 9 − No. 13 Variable Shade)
Cartridge Dimensions 4.33 x 3.54 x 0.39 in. (110 x 90 x 10 mm)
Viewing Field 3.75 x 1.57 in. (95 x 40 mm)
Reaction Time 0.000083 Second (1/12,000)
Available Shades ANSI: Darkened State: No. 9 − 12 / Light State: No. 4
CE/CSA: Darkened State: No. 9 − 13 / Light State: No. 4
Sensors Independent/Redundant (2)
Operating Temperature 23F to 131F (−5C to +55C)
Storage Temperature 14F to 158F (−10C to +70C)
Power Supply Two AAA Alkaline Batteries (Included)
Total Weight 1.01 lb (460g)
Standards ANSI Z87.1-2003 CE/CSA
Warranty 2 Years From Date Of Purchase (See Section 9)
Sensitivity Control light levels Adjusts For Varying Ambient Light And Welding Arc
Delay Control Slows Lens Dark-To-Light State Between 0.1 And
0.5 Second (Fast/Slow Switch)
Automatic Power Off Shuts Lens Off 15−20 Minutes After Last Arc Is Struck
Low Battery Indicator Red LED Light Illuminates To Indicate Low Battery
