Hobby SIESTA VAN - Page 100

Electrical Installations
07-10
13
11
12
Fuses
j
10Afuseforsupplyofoutertentlightorcontrolswitch
fortheheatingelementofthewastewatertank.
k
10Afuseforsupplyoftheradio.Itisdependentonthe
radiobutton.
l
10Afuseforsupplyoftheheating/boiler.Itisdependent
onthemainbutton.
m
20Afuseforsupplyoflightinggroup“A”.Itisdependent
onthemainbutton.
n
20Afuseforsupplyoflightinggroup“B”.Itisdependent
onthemainbutton.
o
30Afuseforsupplyofthe12VAESabsorberrefrigerator.
Therefrigeratorwillturnoffautomaticallywhenthemotor
isswitchedoff.
p
20Afusefortheauxsupply(solarchargercontroller).
 ItisdirectlydependentonB2.
q
25Afusesforsupplyoftheelectricstep.Itisdirectly
dependentonB2.
r
3Afuseforsupplyofgas(refrigerator,kitchen,boiler
valve,etc.).ItisdirectlydependentonB2.
s
3Afuseforprotectionofoutput“simulatedD+”.(Seeno.12.)

14
 Jumperforconnectingabsorptionrefrigeratorrelay.This
connectstherefrigeratordirectlytoB2.

 SimulatedD+generatoroutputthatcontrolstheelectric
entrancestep,electricaldrainvalveandretractionofthe
electricantenna.

 Toswitchbetweenfunctionsforthisvehicle,assetby
themanufacturer,
 A:PC220-HB



 

 
 



 












��� �
















n
n
der
Connections
Electrical devices
1)+Outputheating/boiler,dependenton
mainbutton,fuse
l

2)+Outputradio,dependentonradio
button,fuse
k
3)+Outputoutertentlight/controlswitch
fortheheatingelementofthewaste
watertank,fuse
j
4-5-6)+Outputlightinggroup“B”,
dependentonmainbutton,fuse
m
7-8-9)+Outputlightinggroup“A”,
dependentonmainbutton,fuse
n
