7.6 Fuse protection of the electric system
Ancillary battery
Fusesaremainlyprotectedbya50Asafetyfuse
j
.Thisis
locateddirectlyonthemodularbattery.
12V circuits
Theseareprotectedbyfusesonthe12Vdistributionmodule.
The following applies if one of the devices breaks down
• Checkthefuseonthecorrespondingelectriccircuit.
• Replacethefuse.
• Ifthefuseblowsagainpleasecontactyourauthorized
Hobbydealer.
1
3
2
Circuit breaker
Toprotecttheancillarybatteryfrombeingexhaustively
dischargedwhenthemobilehomeisnotbeingused,acircuit
breaker
j
hasbeeninstalled,whichislocatedunderneath
thevehicle,directlybythedooronthepassenger'sside.
Whentheswitchisopened,themodularbatteryiscompleted
disconnectedfromthe12Vmains.
Thebatterycircuitbreakermustbeonwhenusingthe
vehiclehomeandwhilstdriving.
Whenthecircuitbreakerisopen,theelectricalinput
stagewillnotengageautomatically.
