7.3 Electric power supply
Your motor home has the following connections for electric
powersupply:
- electricmains(a.c.voltage230V)
- caravanbattery(d.c.voltage12V)
Dependingonthemodel,theautomaticcircuitbreakerislocated
eitherintheclothescupboard,inthestepforthebedatthe
rearendofthemobilehome,orinthecupboardunderthebed
attherearendofthemobilehome.
Electric power supply from the electric mains
The230Vsystemisprotectedbya2-polecircuitbreakerwith
16A.
Themobilehomeisconnectedtotheexternal230Vmains
byaCEEfeederplug
j
locatedinthesidewall.
To connect the CEE feeder plug
• Flipupthecoverapoftheexternalsocket
k
(see05-11).
•Completelyunwindtheconnectorcable.
•OpenthecapoftheCEEconnectorplug
l
bypullingitupina
90°angle.
•Inserttheplug
m
untilitlocksintoplace.
To disconnect the electric connection:
• Pressthelever
n
intheexternalsocketdown.
•RemovetheCEEplug
m
.
•Pushthecoverap
k
oftheexternalsocketdownuntilitclicks
intoplace.
