Built-in devices
10-13
To activate
• Push in the knob at position (m) slightly and, at the same
time, move it 90° towards position (k).
• If the switch is in position (k), the knob will remain in posi-
tion (m).
To deactivate
• Turn the switch at position (k) by 90° so that it is parallel to
the frost control.
• At the same time, the knob will jump from position (m) to
position (n).
The drain valve can only be closed manually using
the push button (Position m) and the boiler lled if the
valve temperature is above approx. 7°C.
If the temperature of the safety/drain valve is lower
than approx. 3°C, the push button will be ejected (Po-
sition n) and the contents of the boiler will be drained
off via the drain outlet (o).
The FrostControl is located in all vehicles directly next
to the heating system.
Hot air valve in alcove
The alcove models are equipped with hot air vents in the
alcove bed. The slider
j
is used to regulate the amount of
hot air.
Depending on the model, the hot air slider is located either
on the standing wall of the kitchen unit in the direction of the
passenger seat or in the seating arrangement on the side wall
towards the rear of the mobile home.
