Main control panel display
21 3 4
5
6
7
98 10
11
12
Legend
j
Indicatesthattheprotectionagainstdeepdischargehas
beenactivated.
k
Display:230Vmainsconnection.
l
Display:chargingofthebatteryusingthemotororthe
externalmains.
m
Display:vehicle'smotorhasbeenstarted.
n
Display:llingleveloffreshwatertank.
o
Display:voltageofancillarybattery..
p
Blinkingiconindicatesemptyfreshwatertank.
q
Blinkingiconindicatesemptyancillarybattery.
r
Blinkingiconindicatesfullwastewatertank.
s
Blinkingiconindicatesemptyvehiclebattery.
Displaysthetimeortheselectedfunction.
Displaystheunitsofmeasurement.
11
1 2
Vehicle battery alarm
Ablinkingicondisplaysalarmifthevoltageofthevehicle
batterydropsbelow12V.Thealarmendswhenthevoltageis
higherthan12.5V.
Ancillary battery alarm
Ablinkingicondisplaysalarmifthevoltageoftheancillary
batteryreaches11.5Vandashortbeepwillbeheard.
Ablinkingicondisplaysalarmifthevoltageoftheancillary
batteryreaches10.5Vandtwoshortbeepswillbeheard.
Thealarmendswhenthevoltageishigherthan12.5V.
Functions
