Hobby SIESTA VAN - Page 98

Electrical Installations
07-8
Intelligent Battery Sensor (IBS)*
Thebatterysensormeasuresthecapacityofthestarterand
ancillarybatteriesthatisstillavailable.Italsoshowstheage
ofthebatteries.
Legend
j
DOD display
 Showstheremainingamountoftimeforuseifcurrent
amountofuseiscontinued..
k
Electric power display
 Red=discharge
 Green=charge
l
Electricity as a numerical value
 Example:Currentdischarge:0.1A.
Thespotlightscanalsobeswitchedonmanuallyforeach
lamp.Thespotlightsmustbeswitchedoninordertouse
thecontrolpaneltoswitchthemonandoff.
2
1
3
4
5
6
7
8
Control Panel for Lights

Legend
TI / Van Alcoves Alcove bed
On/Off On/Off On/Off
Bedspotlightleft Alcovespotlightleft Bedspotlightleft
Kitchenceiling Kitchenceiling Kitchenceiling
Ceilinglight,seating
arrangement
Ceilinglight,seating
arrangement
SpotlightsSeatingarrang.
underthealcovebed
Washroom Washroom Washroom
Bedspotlightright Alcovespotlightright Bedspotlightright
Kitchen
Worktoplighting
Kitchen
Worktoplighting
Kitchen
Worktoplighting
Spotlightsseatingarrang.
underthewallcabinet
Spotlightsseatingarrang.
underthewallcabinet
Spotlightsseatingarrang.
underthewallcabinet
----------------
Spotlightsforbedatrear
endofvehicle
Ceilinglightsabovebedat
rearendofvehicle
j
k
l
m
n
o
p
q
r
2
1
3
4
5
6
7
8
9
TI / Van
Alcoves / Alcove bed
45123
