Hobie 16 User Manual

17
hobie.com
Trampoline Assembly - Righting Line
3. Tie the center lacing line.
Start with a bowline knot.
Lace the line back and forth
taking up slack as you go.
When lacing go through the
grommets over/under.
4. Stop the central lacing by
a triangle. Use the central
grommet on the rear trampo-
line stripe. Make a key at the
end.
5. Temporarily tie off the line
at the aft end, then remove
slack again by working it out
front to back. Lace the two aft
lines simultaneously in the
same manner.
Righting line
Attach the righting line to one of the front pylon with a figure eight
knot. Tie the other end to the opposite pylon.
The line should be lead under the trampoline through the center
lacing.

Hobie 16 Specifications

General

Category	Catamaran
Length	16 ft 7 in (5.05 m)
Sail Area	218 sq ft (20.3 m2)
Hull Material	Fiberglass
Weight	320 lbs (145 kg)
Beam	2.41 meters (7.9 feet)
Mast Height	26 ft 6 in (8.07 m)
