Hobie Mirage Outback User Manual

13
hobie.com
Line up the front
of the seat
bottom frame
over key and
slide the back
of the frame
to the molded-
in kickstand
supports.
Put pressure
on the front of
the seat mesh &
lift the back of
the seat bottom
frame to set the
seat into the key.
Push the
seatback frame
down once the
seat frame is fit
into the key.
Pull up on front
of seat to check
for proper
installation.
Flip seat back
up.
Seat Installation
1
2
3
4
Vantage CTW

Hobie Mirage Outback Specifications

General

Drive System	MirageDrive 180 with Kick-Up Fins
Hull Construction	Rotomolded Polyethylene
Capacity	1 person
MirageDrive	MirageDrive 180 with Kick-Up Fins
Rod Holders	4
Width	34" / 0.86 m
Weight Capacity	425 lbs
