Hobie Mirage Outback User Manual

34
If the fins do not stay locked
into position and feel loose,
you’ll need to adjust the kick-
up set screw.
1
2
3
Kick Up Adjustment
Tighten the screw 1/4 turn
at a time until the set screw
just touches the fin.
Test the fin by moving it
in and out of the kick-up
position to determine if it
needs to be tightened or
loosened.
Make sure that the fin is
completely engaged into
the sprocket.
The set screw is located in
the housing at the base of
the fin.
4mm hex
wrench
included

Hobie Mirage Outback Specifications

General

Drive System	MirageDrive 180 with Kick-Up Fins
Hull Construction	Rotomolded Polyethylene
Capacity	1 person
MirageDrive	MirageDrive 180 with Kick-Up Fins
Rod Holders	4
Width	34" / 0.86 m
Weight Capacity	425 lbs
