Hobie Mirage Outback User Manual

23
hobie.com
Fishfinder Option
3
For most side imaging
transducers, we recommend
using the mounting bracket
included with your fish finder
as a drill template for
creating mounting holes in
the Guardian plate.
4
Some side imaging
transducers, like the
Lowrance TripleShot, will
mount through the bottom
of the transducer guard and
to the post on the inside of
the Guardian plate. For these
units, refer to the Skimmer
Style Transducer Installation.
If the transducer is not sitting
flush with the shield, 2 small
holes (one on each side of the
transducer) can be drilled
and a zip tie used to secure
the transducer to the shield.
TripleShot hardware
configuration

Hobie Mirage Outback Specifications

General

Drive System	MirageDrive 180 with Kick-Up Fins
Hull Construction	Rotomolded Polyethylene
Capacity	1 person
MirageDrive	MirageDrive 180 with Kick-Up Fins
Rod Holders	4
Width	34" / 0.86 m
Weight Capacity	425 lbs
