Hobie Mirage User Manual

24
Locate the thru-hull
plug and unscrew the
nut on the inside of
the boat.
Gasket
Gasket
Remove the solid
rubber plug.
Choose the correct
plug for your wire
size and insert the
wire by opening the
plug along the slit.
Press the new plug
with the wire
installed into the
plastic plug making
sure it fits tightly.
DO NOT USE A
DRILL for the three
way plug. Bolt or
screw the thru-hull
wire assembly to the
hull using the nut or
screws. Make sure
you have the o-ring
or gasket installed.
Thru-Hull Plugs Single and 3-way
1
2
3
4
5
Lowrance Ready Option

Hobie Mirage Specifications

General

Category	Kayak
Hull Material	Rotomolded Polyethylene
MirageDrive	Yes
Rudder	Yes
Propulsion	Pedal-driven (MirageDrive)
Storage	Bow and stern hatches, tankwell
