Hoffer Flow Controls HIT-4U - Page 18

Installation 13
HIT-4U HP-327
SW1
PCA1 92
HofferFlowContro ls
TxA
TxB
TB3
123456
TB2
Flow+
Flow‐
TB1
DC+
DC‐
Analog
Load
+
‐
Magnetic
Pickup
RS485
RS485
A
B
Loop Powered with Magnetic Pickup
SW1
PCA1 92
HofferFlowContro ls
TxA
TxB
TB3
123456
TB2
Flow+
Flow‐
TB1
DC+
DC‐
Analog
Load
+
‐
Con tact
Clo sure
RS485
RS485
Loop Powered with Contact Closure
