4 Introduction
HP-327 HIT-4U
INPUT POWER
MODEL HIT-4(
)-( )-( C )-( )-( )-( )-( )-( )-( )-( )
OPTION
( C )
(B) BATTERY POWERED
NOTE: MAG ONLY, NO ANALOG, PULSE, OR ALARM
(L) 2-WIRE, 4-20MA LOOP POWERED 8-30VDC
NOTE: MAG ONLY, NO PULSE OR ALARM
(D) 12 TO 30 VDC POWERED
NOTE: 4-20MA ANALOG OUT INCLUDED
(AC) AC POWERED UNIVERSAL 100-240VAC @ 0.15A 50/60 HZ
NOTE: NOT AVAILABLE FOR Ex d CERTIFIED SYSTEMS
4-20MA ANALOG OUT INCLUDED
PULSE INPUT
MODEL HIT-4(
)-( )-( )-( D )-( )-( )-( )-( )-( )-( )
OPTION
( D )
(M) MAGNETIC COIL, DRY CONTACT
(R) ISOLATED PULSE, RPM, RPR, HALL EFFECT COILS
(RF) MODULATED CARRIER COIL
PULSE OUTPUT
MODEL HIT-4(
)-( )-( )-( )-( E )-( )-( )-( )-( )-( )
OPTION
( E )
(5*) 0-5V TTL/CMOS
(OC*) OPEN COLLECTOR
* INSERT (R) FOR RAW FREQUENCY PULSE OUTPUT
NOTE: NOT AVAILABLE WITH (B) OR (L) POWER INPUTS
ALARM - WITH USER-DEFINED LEVELS FOR RATE AND/OR TOTAL
MODEL HIT-4(
)-( )-( )-( )-( )-( F )-( )-( )-( )-( )
OPTION
( F )
(5) 0-5V TTL/CMOS
(OC) OPEN COLLECTOR
NOTE: NOT AVAILABLE WITH (B) OR (L) POWER INPUTS
COMPENSATION METHOD-TEMP/PRESSURE LIQ/GAS
MODEL HIT-4(
)-( )-( )-( )-( )-( )-( G )-( )-( )-( )
OPTION
( G )
(X) NO COMPENSATION, ALWAYS USE X ON HIT-4U
DEFAULT TEMPERATURE / PRESSURE COMPENSATION ON HIT-4G
(TP1_) TEMPERATURE AND PRESSURE TRANSMITTER INPUTS (4-20MA)
(TP2_) 100 OHM RTD (DIN385) / PRESSURE TRANSMITTER INPUTS
(4-20MA)
