JEL3 TECHNICAL MANUAL
6.0 TABLES
6.1 PRESSURE VS. TEMPERATURE
The following table shows the relationship between steam pressure in pounds
per square inch (psig), and temperature in degrees Fahrenheit (ºF). This table
can be useful in determining the steam temperature at a corresponding
pressure. It is helpful in setting the pressure when the steam generator is
connected to auxiliary equipment that requires temperature adjustment.
Table 6.1.1
Pressure (psig) Temperature (ºF)
1 213
5 228
10 240
15 250
20 259
25 267
30 274
35 281
40 287
45 293
50 298
55 303
60 308
65 312
70 316
75 320
80 324
85 328
90 331
95 335
100 338
6.2 ELECTRICAL SPECIFICATIONS
The following table illustrates the voltage and amperage requirements of the
various models of Steam Generators.
Table 6.2.1
MODEL
NUMBER
KW VOLTAGE PHASE AMPS
JEL-1 1.5 120 1 13
JEL-2 1.5 240 1 7
JEL-3 1.5 120 1 13
JEL-4 1.5 240 1 7
JEL-6 3.0 240 1 13
ELG-4 1.5 120 1 13
ELG-4.2 1.5 240 1 7
ELG-5 1.5 120 1 13
ELG-5.2 1.5 240 1 7
ELG-6 3.0 240 1 13
ELG-7 3.0 240 1 13
7.0 DRAWINGS & PARTS LIST
Figure 7.1 -Assembly for Models: JEL-1, JEL-2, JEL-3, JEL-4, JEL-6, ELG-4, ELG-4.2,
ELG-5, ELG-5.2, ELG-6, ELG-7
Figure 7.2 -52488 (rev B) Wiring Diagram for Models: JEL-1, JEL-2, JEL-3, JEL-4,
JEL-6, ELG-4, ELG-4.2, ELG-5, ELG-5.2, ELG-6, ELG-7
Optional Parts List
For Original Quality Parts: 1-800-484-3013
