ENGLISH
Use and maintenance manual
Setup
7.4.2 Diameter gauge calibration E
1. Display the diameter gauge CALIBRATION function from the SETUP menu
2. Place the gauge rod on the spindle shell as shown in the figure and press
ENTER
3. Turn the gauge downward positioning the gauge rod in contact with the spindle sleeve as shown in the
figure and press
ENTER
CALIBRATION COMPLETE
▪ Return the gauge to rest position.
▪ The wheel balancer is ready for operation.
In case of errors or malfunctions, the indication of the same step [P.1] or [P2], always reappears on the display. Move the gauge back into rest
position and repeat the calibration operation as described above; if the error persists, contact Technical Service.
If erroneously accessing the diameter gauge calibration function, press
STOP
to cancel it.
After calibrating the distance gauge, the diameter gauge or both, always calibrate the Spotter.
