ENGLISH
Use and maintenance manual
Setup
The two adhesive weights must be securely applied in order to execute two measurements using the automatic
distance and diameter gauge and two spotter device positions using the on-display buttons.
If you accidentally lose a weight during calibration, the procedure needs to be repeated from scratch.
During calibration, use the automatic distance and diameter gauge with the necessary accuracy.
1. Display the spotter device CALIBRATION function from the SETUP menu
2. Move the distance gauge feeler pin near the first adhesive weight and press
ENTER
3. Move the distance gauge feeler pin near the inner-most adhesive weight and press
ENTER
