5. SPECIFICATIONS
Accuracy is guaranteed for 1 year under conditions : 23 ° C ± 5 ° C, humidity below 80% RH
5-1. DC voltage (automatic range setting)
Range Resolution Accuracy
600 mV 0.1 mV ±(0.8% reading + 5 digits)
6 V 1 mV
±(0.8% reading + 3 digits)
60 V 10 mV
600 V 100 mV ±(1.0% reading + 5 digits)
Input impedance: 10 MΩ
Overload protection: 600 V DC / AC rms
Max. Input voltage: 600 V DC
5-2. AC current (automatic range selection)
Range Resolution Accuracy
2-20 A 100 mA
±(3.0% reading + 5 digits)
200-600 A 1 A
Voltage drop measurement: 200 mV
Frequency range: 40 to 200 Hz
5-3. AC voltage (automatic range selection)
Range Resolution Accuracy
600 mV 0.1 mV ±(1.2% reading + 8 digits)
6 V 1 mV
±(1.0% reading + 8 digits)
60 V 10 mV
600 V 100 mV ±(1.2% reading + 8 digits)
Input impedance: 10 MΩ
Frequency range: 40 Hz ~ 400 Hz
Overload protection: 600 V DC / AC rms
Answer: Average, calibrated in rms sinusoidal wave
Max. Input voltage: 600 V AC rms
Overload protection: 250 V DC / AC rms
5-4. Resistance (automatic range selection)
Range Resolution Accuracy
600 Ω 0.1 Ω
±(1.5% reading + 5 digits)
6 KΩ 1 Ω
60 KΩ 10 Ω
600 KΩ 100 Ω
6 MΩ 1K Ω
60 MΩ 10 KΩ
Open circuit voltage: about 0.25 V.
Overload protection: 250 V DC / AC rms
