Hohner EXACT - Safety-Related Components; Mounting of the Finger Guard

Structure and function of the machine
Hohner Maschinenbau GmbH EXACT 06/2010 11
3.1 Safety-related components
- Fig. 2.1 -
The combined ON/EMERGENCY-STOP button -1-, the door safety switch -2- and the
finger guard -3- are essential for the safe function of the machine.
3.2 Mounting of the finger guard
The finger guard must be mounted and adapted to the block- and brochure stitching. Mounting is
simplified by corresponding symbols which are sticked on the finger guard.
Fit the finger guard -1- for block- and brochure stitching as shown below.
Flat stitching
Brochures stitching
Quick stroke movements of the stitching heads!
Danger of crushing!
¾ Never operate the system without properly mounted finger guard.
