Hohner EXACT - Pressure Adjustment for Clincher Back Press; Installation of Centering Device and Rider for Stitching Brochures

Structure and function of the machine
Hohner Maschinenbau GmbH EXACT 06/2010 19
3.8 Pressure adjustment for clincher back press
- Fig. 3.7 -
- Remove the finger guard.
- Open the front plate.
- Loosen the slotted set screw -3-, turn the hexagon head bolt -4-, counter clockwise to increase
pressure or clockwise to decrease pressure.
- Now re-secure slotted set screw -3-.
It is very important that the groove-middle of the driver -1- and the middle of the
clincher box -2- coincide absolutely.
- Mount the finger guard in the correct position and note the markings (see 3.2).
- Close the front door.
3.9 Installation of centering device and rider for stitching brochures
See stitching head operating instructions.
