Description of the Saddle Binder EXACT
Hohner Maschinenbau GmbH EXACT 06/2010 9
2.1 Dimensions
- Fig. 2.1 -
2.2 Conformity
Please observe the document attached:
„EC Declaration of Conformity according to the EC Machinery Directive 2006 / 42 / EC“
2.3 Marking and type plate
The type plate and the CE labelling are fitted below the main switch - Fig. 2.1 -, Pos. 1.
2.4 Technical data
Stroke - narrow stitching head 50 mm
Stroke - clincher 5.5 mm
Table size 550 x 280 mm
Max. breadth for brochures 320 mm
Max. distance from staple to machine stand (throat) 170 mm
Max. setting dimension for narrow stitching heads 330 mm
Max. sheets thickness for flat stitching ca. 8 mm
Max. sheets thickness for loop stitching ca. 3 mm
Stitching wire for flat stitching
* Wire sizes corresponding to german standards!
Standard for round wire
Nr. 24-28*
(0.60-0.40 mm)
or, optional for round wire
Nr. 26-30*
(0.50-0.35 mm)
or, optional for flat wire
Nr. I-III*
(0.70 x 0.35-0.75 x 0.55 mm)
Stitching wire for loop stitching only for round wire
Nr. 24-26 (0.60-0.50 mm)
Net weight of the machine with stitching heads ca. 150 kg
Motor-Standard execution 0.37 kW
for 230/400 Volts
3-phase A.C., 50 cycles
Loudness level not over 81 dB(A)
