Black plate (63,1)
Holden WM Caprice Owner Manual (MY12.5) - 2012 - CRC 1st Edition - 6/28
12
Vehicle Care 10-63
WARNING (Continued)
of water, but should also seek
medical help. Battery acid
also damages paint and
fabrics. To minimise damage,
wash it off immediately.
.
Remove rings, metal watch
bands and other metal
jewellery before working
around the battery.
.
If a permanently connected
hands free telephone kit is
fitted to the vehicle, remove
the fuse for the telephone kit
before jump starting.
Remember to replace the
fuse afterwards.
Jump starting connection posts
The jump start positive (A) and
negative (B) posts are located in the
engine bay on the passenger side.
These posts are used instead of a
direct connection to a battery.
The positive jump start connection
is covered by a red cap.
1. Push the clip to release the top.
2. Remove to expose the terminal.
{
CAUTION
Do not make any connections at
point (C) as costly damage to the
vehicle could result.
