Holder C992 - Snow Blower Parts List

Box Snow Blower January 2013
Owner’s Manual and Parts List
Page 25 of 28 Holder tractors Inc. www.holdertractors.ca
SNOW BLOWER PARTS LIST
# -- Description ---------------------------------------------------------- Fig --- Part # ------------------------- Qty.
1---- Drive shaft Assembly ---------------------------------------------- Fig 9, 17 --- M-SB-XX-150 ----------------- 1
2---- Cylinder 1.5" Bore x 4" or 6" STK x 1" Rod --------------------- Fig 17 --- M-SB-XX-151 ----------------- 1
3---- Parking Leg Assembly --------------------------------------- Fig 3, 9 & 17 --- M-SB-XX-152 ----------------- 1
4---- Retaining Plate --------------------------------------------------- Fig 8 & 18 --- M-SB-XX-033 ----------------- 2
5---- Flange Bearing ---------------------------------------------- Fig 7, 18 & 18 --- M-SB-XX-077 ----------------- 5
6---- Fan Assembly ------------------------------------------------------ Fig 7& 18 --- M-SB-XX-155 ----------------- 1
7---- Lower Chute Assembly --------------------------------------- Fig 12 & 18 --- M-SB-XX-156 ----------------- 1
8---- Rotational Ring Assembly -------------------------------------- Fig 8 & 18 --- M-SB-XX-157 ----------------- 1
9---- Lower Hitch Assembly ----------------------------------------------- Fig 17 --- M-SB-XX-159 ----------------- 2
10 -- Drive line Guard Assembly ----------------------------------------- Fig 17 --- M-SB-XX-160 ----------------- 1
11 -- Swivel Base Assembly ----------------------------------------------- Fig 17 --- M-SB-XX-161 ----------------- 1
12 -- Lower Auger Assembly ------------------------------------ Fig 7, 12 & 18 --- M-SB-XX-162 ----------------- 1
13 -- Upper Auger Assembly ----------------------------------------- Fig 7 & 18 --- M-SB-XX-163 ----------------- 1
14 -- Upper Chute Assembly --------------------------------------- Fig 12 & 17 --- M-SB-XX-164 ----------------- 1
15 -- Middle Chute Assembly -------------------------------------- Fig 12 & 17 --- M-SB-XX-165 ----------------- 1
16 -- Auger Chain Tensioner Assembly -------------------- Fig 11, 14 & 17 --- M-SB-XX-166 ----------------- 1
17 -- Chute Chain Tensioner Assembly -------------------------------- Fig 18 --- M-SB-XX-167 ----------------- 1
18 -- Hydraulic Hose Support Assembly --------------------------- Fig 8 & 18 --- M-SB-XX-169 ----------------- 1
19 -- Auger Drive Chain Cover Assembly ------------------------------ Fig 18 --- M-SB-XX-170 ----------------- 1
20 -- Chute Tensioner Bracket Assembly ------------------------------ Fig 18 --- M-SB-XX-171 ----------------- 1
21 -- Chain # 60H x 120 Links --------------------------- Fig 11, 14, 16 & 17 --- M-SB-XX-173 ----------------- 1
22 -- Support Bracket R/H -------------------------------------------- Fig 7 & 18 --- M-SB-XX-007 ----------------- 1
23 -- Support Bracket L/H ---------------------------------------------- Fig 7& 18 --- M-SB-XX-008 ----------------- 1
24 -- Angle mounting Plate -------------------------------------------------- Fig 9 --- M-SB-XX-011 ----------------- 1
25 -- Drive Shaft Sprocket ------------------------------------------------- Fig 18 --- M-SB-XX-016 ----------------- 1
26 -- Chain Cover ------------------------------------------------------------ Fig 17 --- M-SB-XX-023 ----------------- 1
27 -- Auger Chain Guard -------------------------------------------- Fig 16 & 17 --- M-SB-XX-026 ----------------- 1
28 -- Top Chain Guard ------------------------------------------ Fig 10, 15 & 17 --- M-SB-XX-175 ----------------- 1
29 -- Drive Shaft Cover ----------------------------------------------------- Fig 18 --- M-SB-XX-045 ----------------- 1
30 -- Skid Shoe R/H ---------------------------------------------------- Fig 7 & 18 --- M-SB-XX-047 ----------------- 1
31 -- Skid Shoe L/H ----------------------------------------------------- Fig 7 & 18 --- M-SB-XX-048 ----------------- 1
32 -- Cutting Edge ------------------------------------------------------ Fig 7 & 18 --- M-SB-XX-059 ----------------- 1
33 -- Chute Arm ------------------------------------------------------- Fig 12 & 17 --- M-SB-XX-070 ----------------- 2
34 -- Hydraulic Hose Storage Bracket ---------------------------------- Fig 17 --- M-SB-XX-108 ----------------- 2
35 -- Hydraulic Straight fitting ----------------------------------------- Fig 9 O/L --- 3/8x1/2 Flat face coupler--- 4
36 -- Stick Flag --------------------------------------------------------------- Fig 17 --- M-SB-XX-118 ----------------- 1
37 -- Chain # 60 x 81 Links ------------------------------------------- Fig 8 & 18 --- M-SB-XX-174 ----------------- 1
38 -- Flange Bearing Spacer --------------------------------------- Fig 13 & 17 --- M-SB-XX-116 ----------------- 1
39 -- Flange Bearing Mounting Plate ------------------------------------ Fig 18 --- M-SB-XX-117 ----------------- 1
40 -- Hydraulic Motor -------------------------------------------- Fig 10, 15 & 18 --- M-SB-XX-088 ----------------- 1
41 -- Gearbox ------------------------------------------------------------ Fig 9 & 17 --- M-SB-XX-078 ----------------- 1
42 -- Pin 3/4" Dia. x 5-1/2" Long ----------------------------------- Fig 12 & 17 --- M-SB-XX-119 ----------------- 2
43 -- Pin 3/4" Dia. x 4-1/2" Long ----------------------------------- Fig 13 & 17 --- M-SB-XX-120 ----------------- 1
44 -- Pin 7/8" Dia. x 4-1/2" Long ----------------------------------- Fig 13 & 17 --- M-SB-XX-121 ----------------- 2
45 -- Idler Sprocket (chute) ------------------------------------------------ Fig 18 --- M-SB-XX-086 ----------------- 3
